Additional modeling was carried out in Autodesk Fusion 360 before being prepared in GrabCAD print and sent for printing. Using the Space Spider, the team created an accurate, true-to-life model for 3D printing within the space of an hour from data capture through to CAD model in Artec Studio.
The Center console component featured a glossy black finish, a surface that is notoriously difficult to 3D scan, and as such was coated with matting spray prior to scanning. Photo via National Geographic.ĭeveloped for us on the International Space Station, the Artec Space Spider was chosen to complete the 3D scan of the Ford Cortina for its ability to capture complex shapes and fine details with accuracy of up to 0.05 mm and ultra-high resolution of up to 0.1 mm. Artec Space Spider is getting ready to scan Ford Cortina’s Nark III center console at the Central Scanning workshop. However, the search proved unsuccessful and instead the team turned to 3D scanning to produce a replica of a console they managed to borrow for a few days.Ĭar SOS then brought in Central Scanning, who has past experience scanning everything from entire cars to chassis, engine parts, interior parts and suspension components for classic cars. After inspecting the vehicle, the team found that the center console was missing and sought to source a new one. To see Singh’s automotive dream resurrected, his family contacted the Car SOS team to complete the restoration. Unfortunately, the project came to a screeching halt in 2002 when Singh suffered a stroke and was later diagnosed with heart disease and a brain tumor.
The 1970s Ford Cortina belongs to historian and writer Bobby Singh, who bought the car back in 1999 with plans to restore it.
#Stratasys product timeline 3d printers fortus tv#
Car SOS TV hosts (left and center) and Bobby Singh, owner of the restored Ford Cortina Mark III after the grand reveal (right). Having leveraged 3D scanning for previous projects, the team reached out to 3D scanner manufacturer Artec’s UK ambassador, Central Scanning, to assist with replicating the console, and printed the component using a Stratasys Fortus 400mc 3D printer. Unable to find a replacement for the console, a common problem when sourcing parts to restore classic cars, the car SOS team turned to 3D scanning and printing to produce the component within the show’s tight timeline. Popular British automotive TV show Car SOS, aired on National Geographic, has used 3D scanning and 3D printing to restore the customized central console of a 1970’s Ford Cortina Mark III X. *Compatible with GrabCAD Print for use with job reports, scheduling, and remote monitoring.Nominations for the 2021 3D Printing Industry Awards are now open, have your say who is leading the industry now. Design, engineering, and manufacturing teams can network and share 3D manufacturing capacity to maximize efficiency and throughput.
#Stratasys product timeline 3d printers fortus software#
This sophisticated software application communicates with user workstations and Fortus systems, to manage jobs and monitor production status. Manipulate tool paths for advanced control over part properties Program pauses into the build for any reason, such as to embed hardware or circuitry Optimize build orientation for maximum strength and smoothest surface finishĬustomize supports for fast, easy removal and best use of materials For maximum control, users can manually edit parameters that determine the look, strength, and precision of parts as well as the speed and material use of the FDM process. Insight software prepares your CAD program’s STL output for 3D manufacturing on a Fortus machine by automatically slicing and generating support structures and material extrusion paths.
